DeepCool AK700 DIGITAL NYX CPU Cooler
The DeepCool AK700 DIGITAL NYX builds on the renowned AK DIGITAL series with enhanced cooling performance and a striking new aesthetic. Featuring seven copper heat pipes, a dense single-tower heatsink, a newly designed silent fan, and a high-end quad-segmented digital display, it delivers powerful CPU cooling with intuitive real-time monitoring.
Next-Generation Performance
- Utilizes DeepCool’s latest Core Touch Technology (CTT 2.0)
- Optimized single-tower heatsink design
- Seven advanced copper heat pipes for improved heat transfer
- Precision-machined copper base for efficient thermal conductivity
Quad-Segmented Digital Display
The standout feature of the AK700 DIGITAL NYX is its upgraded quad-segmented digital display, providing real-time system insights, including:
- CPU temperature
- CPU usage
- CPU wattage
- CPU frequency
The display is controlled via DeepCool software and requires an available USB 2.0 header.
AI-Tuned Cooling with DeepCreative
Powered by the upgraded DeepCreative interface, this cooler eliminates the need for manual BIOS adjustments:
- AI-driven algorithm tracks CPU load in real time
- Automatically matches the optimal fan speed curve
- Balances powerful cooling with whisper-quiet operation
- One-click control for effortless optimization
Proven AK-Series Design
Continuing the AK legacy, the AK700 DIGITAL NYX features:
- Seven copper heat pipes for enhanced heat dissipation
- Signature matrix fin array in a single-tower layout
- Efficient airflow and cooling for high-performance systems
Premium Compatibility
Designed with offset heat pipes to support the deeper heatsink:
- Improved clearance for tall RAM heat spreaders
- Unobstructed view and access to all RAM slots
- Better component compatibility within your build
Cool, Quiet, and Powerful
The newly designed fan delivers smooth, low-noise operation:
- High-quality hydraulic (hydro) bearing
- Three-phase, six-slot, four-pole motor for stable performance
- Engineered for both strong airflow and quiet acoustics
Multi-Platform Support
Durable mounting hardware ensures:
- Simple, straightforward installation
- Proper contact and even mounting pressure
- Compatibility with mainstream Intel and AMD platforms
Specifications
| Item |
Specification |
| Product Dimensions (L × W × H) |
126 × 98 × 157 mm |
| Heatsink Dimensions (L × W × H) |
124 × 76 × 151 mm |
| Net Weight |
1252 g |
| Heatpipe |
6 mm × 7 pcs |
| Fan Dimensions (L × W × H) |
120 × 120 × 25 mm |
| Fan Speed (max) |
2700 ±10% RPM |
| Fan Airflow |
77.23 CFM |
| Fan Air Pressure |
5.13 mmAq |
| Fan Noise |
21.0 / 28.8 / 36.0 dB(A) |
| Fan Connector |
4-pin PWM |
| Bearing Type |
Hydro Bearing |
| Fan Rated Voltage |
12 VDC |
| Fan Rated Current |
0.35 A |
| Fan Power Consumption |
4.2 W |
| Display Module Rated Current |
0.13 A ±10% |
| Display Module Rated Voltage |
5 VDC |
| Display Module Power Consumption |
0.65 W |
| Display Area |
29 × 39 mm |
